Metal Roofing Panel Rolling Machine (YX25-210-840)

Xiamen Xinhonghua Machinery Co., Ltd.
  • Type：Rolling Machine
  • Forging Forming Method：Cold Roll Forming Machine
  • Power Source：Electric
  • Feature：Automation
  • Warranty：12 Months
  • Customized：Customized

Base Info

  • Model NO.：YX25-210-840
  • Advantage：Easy to Maintenance
  • Condition：New
  • Dimension：6000*1500*1500mm
  • Hydraulic Power：1.5kw
  • Motor Power：4kw
  • Voltage：380V,50Hz,3pH
  • Material Thickness：0.3-0.6mm
  • Processing Speed：8-14m,Min
  • Forming Step：14 Steps
  • Material Width：1000mm
  • Effective Width：840mm
  • Height of Roof：25mm
  • Transport Package：Standard Export Package
  • Specification：SGS
  • Trademark：XHH
  • Origin：Xiamen of China
  • HS Code：84552290
  • Production Capacity：20 Sets,Month

Description

Basic Info.

Model NO. YX25-210-840 Advantage Easy to Maintenance Condition New Dimension 6000*1500*1500mm Hydraulic Power 1.5kw Motor Power 4kw Voltage 380V/50Hz/3pH Material Thickness 0.3-0.6mm Processing Speed 8-14m/Min Forming Step 14 Steps Material Width 1000mm Effective Width 840mm Height of Roof 25mm Transport Package Standard Export Package Specification SGS Trademark XHH Origin Xiamen of China HS Code 84552290 Production Capacity 20 Sets/Month

Product Description

Specification

The detail information of YX25-210-840 Metal Roofing Panel Rolling Machine,Steel Roof Rolling Machine, Roof Rolling Machine are as following:


Main Accessories:

(1) Main Forming Machine;
(2) 5 Tons Manual Uncoiler;
(3) Hydraulic System;
(4) PLC Computer Controlling System with Touch Screen
(5) Hydraulic Forming Cutter;
(6) Run Out Tables(3 Units);
(7) Tools;
(8) Operation Manual.

Main Technical Data:

1.		Motor Power4KW
2.Hydraulic Power1.5KW
3.Voltage380V/50HZ/3PH
4.Material Width1000mm
5.Effective Width840mm
6.Material Thickness0.3-0.6mm
7.Working Speed8-14m/min
8.Forming Steps14 steps
9.Height of Roofing25mm
