Steel Pipes Mandrel Bar Used for Seamless Steel Tubes and Pipes Rolling
Yantai Fangle Metallurgy Group Co., Ltd.- Condition：New
- Certification：CE, ISO9001
- Standard：DIN, ASTM, GB
- Customized：Customized
- Material：Alloy
- Application：Metal Processing Machinery Parts
Base Info
- Model NO.：as the drawing
- Application Range：Continuous Rolling Mill,Mpm,Fqm,Pqf
- Transport Package：Woodern Case
- Specification：max 20m, Diameter 100mm-500mm
- Trademark：FANGLE
- Origin：China
- Production Capacity：50000tons,Year
Description
Mechanical properties
Tensile strength: RM = 1050 MPa Minimum (105 kg/mm²)
RM = 1280 MPa Maximum (130 kg/mm²)
Yield strength: Ys ≥ 880 MPa
Elongation: Min .A=10%
Reduction of area: Min.Z=30%
Charpy V-Notch impact test: Min. Kv ≥ 20j, testing at room temperature.
Charpy tests will be in transverse orientations.
Application
- MPM-mill
- Continuous tube mill
- Push bench
- Assel mill
