C 75 Profile Roll Forming Machine with Post-Cutting
Xiamen Xinhonghua Machinery Co., Ltd.- Type：Hydraulic Machine
- Forging Forming Method：Tire Mold Forging
- Power Source：Hydraulic Pressure
- Feature：Automation
- Certification：SGS
- Warranty：12 Months
Base Info
- Model NO.：C75
- Customized：Customized
- Advantage：Use Widely
- Condition：New
- Size：C75
- Dimension：6000*1400*1100mm
- Weight：3000kgs
- Hydraulic Motor Power：11kw
- Forming Steps：13+3 for Reshaped
- Effective Width：75mm
- Working Speed：10-15m,Min
- Voltage：380V,50Hz,3pH
- Material Thickness：0.7-1.5mm
- Transport Package：Standard Package for Export
- Specification：SGS
- Trademark：XHH
- Origin：Xiamen, China
- Production Capacity：20sets,Month
Description
Basic Info.
Model NO. C75 Customized Customized Advantage Use Widely Condition New Size C75 Dimension 6000*1400*1100mm Weight 3000kgs Hydraulic Motor Power 11kw Forming Steps 13+3 for Reshaped Effective Width 75mm Working Speed 10-15m/Min Voltage 380V/50Hz/3pH Material Thickness 0.7-1.5mm Transport Package Standard Package for Export Specification SGS Trademark XHH Origin Xiamen, China Production Capacity 20sets/MonthProduct Description
Detail information for C75 Profile Roll Forming Machine with Post-cutting ,C Purline Forming Machine,Purline Machine are as follow:Main Accessories:
(1) Main Forming Machine;
(2) 5 Tons Manual Un-coiler ;
(3) Hydraulic System;
(4) PLC Computer Controlling System With Touch Screen( Brand: Schneider);
(5)Hydraulic Forming Cutter;
(6) Run out tables(3 PCS);
(7) Operation Manual;
(8)Tool
Main Technic Data:
| 1. | Size | C75 |
| 2. | Dimension | 6000*1400*1100mm |
| 3. | Weight | 3000KGS |
| 4. | Hydraulic Motor Power | 11KW |
| 5. | Forming Steps | 13+3 for reshaped |
| 6. | Effective Width | 75mm |
| 7. | Working Speed | 10-15m/min |
| 8. | Voltage | 380V/50HZ/3PH |
| 9. | Material Thickness | 0.7-1.5mm |
