380V Roll Forming Corrugated Extrusion Making Line Optical Cable Wire
JIANGSU RELIABLE INDUSTRY CO., LTD.- Control Type：PLC
- Customized：Customized
- Condition：New
- Automatic Grade：Semi-Aotumatic,Aotumatic
- Main Motor Power of Extruder：110kw,132kw,200kw,250kw
- Transport Package：Wooden Package
Base Info
- Specification：Customized
- Trademark：Reliable
- Origin：China
Description
Round aluminum tube, porous aluminum flat tube, aluminum strap wire, aluminum conductor, aluminum bar (profile), etcAluminum bar 3 Nominal Diameter Of Extrusion Wheel ∅285 ∅315 ∅340 ∅400 4 Main Motor Power Of Extruder 110KW 132KW 200KW 250KW 5 Rated Speed Of Main Machine 16r/min 18r/min 20r/min 20r/min 6 Max. Production Speed 14m/min 16m/min 20m/min 25M/min 7 Product Diameter ∅20mm ∅25mm ∅30mm ∅60mm 8 Output Aluminium tube: 150kg/h Aluminium tube: 180kg/h Aluminium tube: 360kg/h 450kg/h 9 Leak Amount ≤5% ≤5% ≤5% ≤5% 10 Raw Material: Oxygen-Free Copper Rod ∅9.5mm Aluminum rod: ∅9.5mm 2×∅9.5mm Aluminum rod: 2×∅9.5mm ∅15mm
Aluminum rod: ∅15mm ∅15mm
Aluminum rod: ∅15mm
4.Layout:
5.Application Demonstration:
Extruded products are soft, using wire reel winding, also can be euqipped with a wire cutting saw.
Product improves product hardness by drawing, and it is equipped with wire cutting saw length cutting at the same time, automatic material reck to arrange and shape products for easy packaging.
Irregular conductor can be extruded
High quality aluminum tube can be extruded
