Optical Edge Detector 300mm Screen Digital Profile Projector
Laizhou Laihua Testing Instrument Factory- After-sales Service：Technical Guidance
- Transport Package：Wooden
- Specification：700*850*990
- Trademark：Laihua
- Origin：China
Base Info
- Model NO.：CT-3000
- Production Capacity：100 Set
Description
CPJ-3007
CPJ-3007ZCPJ-3010
CPJ-3010Z CPJ-3015
CPJ-3015Z X-axis Travel (mm) 75 100 150 Y-axis Travel (mm) 50 50 50 Metal table size (mm) 260×152 306×152 340×152 Glass table size (mm) 125×100 175×100 196×96 Resolution (μm) 0.5 Indication error (mm) E1XY=(2.5+L/100) E1XY=(2.5+L/75) E1XY=(3+L/50) Z-axis Travel (mm) 90 (focusing) Weight (kg) 120 125 130 Dimension (mm) 770×550×1100 770×550×1100 770×550×1100 Projection screen Size (mm) Ф 312 Rotary range 0~360° Resolution 1' or 0.01° Lens Magnification 10× (Optional) 20× (Optional) 50× (Optional) 100× (Optional) Field of view (mm) Ф30 Ф15 Ф6 Ф3 Working distance (mm) 77.7 44.3 38.4 25.3 Max. measuring Height (mm) 80 80 80 80 Power supply: AC 100-240V 50/60Hz. Total power: 400W
Packaging and shipping
Packaging: Standard export package, wooden case
Delivery: 3 days upon receipt of payment, depend on order quantity
Company Information:
Laizhou LaiHua Testing Instrument Factory was founded in 2010,which specializes in the manufacture of hardness testers and metallographic equipments for metaland nonmetal materials. Besides, we can also design special, large-scale dedicated machines according to the requirements of customers.
CPJ-3007Z
CPJ-3010Z
CPJ-3015Z
Packaging and shipping
Packaging: Standard export package, wooden case
Delivery: 3 days upon receipt of payment, depend on order quantity
Company Information:
Laizhou LaiHua Testing Instrument Factory was founded in 2010,which specializes in the manufacture of hardness testers and metallographic equipments for metaland nonmetal materials. Besides, we can also design special, large-scale dedicated machines according to the requirements of customers.
