• Model NO.：KLS38-220-530
• Customized：Customized
• Advantage：Work Flexible
• Condition：New
• Motor Power：2.2kw
• Power for Hydraulic Forming Cutter：0.75kw
• Forming Steps：8 Steps
• Delivery Time：Delivery Immediately After The Machine Is Assemble
• After-Sales Service：Engineers Available to Service Machinery Overseas
• Forming Speed：6-12m,Min
• Roller Material：45#Steel
• Shaft Material：40cr
• Clipper Material：10crmov
• Weight：1500kgs
• Transport Package：Standard Package for Export
• Trademark：XHH
• Origin：Xiamen of China
• HS Code：84552290
• Production Capacity：20 Sets,Month

Basic Info.

Model NO. KLS38-220-530 Customized Customized Advantage Work Flexible Condition New Motor Power 2.2kw Power for Hydraulic Forming Cutter 0.75kw Forming Steps 8 Steps Delivery Time Delivery Immediately After The Machine Is Assemble After-Sales Service Engineers Available to Service Machinery Overseas Forming Speed 6-12m/Min Roller Material 45#Steel Shaft Material 40cr Clipper Material 10crmov Weight 1500kgs Transport Package Standard Package for Export Trademark XHH Origin Xiamen of China HS Code 84552290 Production Capacity 20 Sets/Month

Product Description

Informations of KLS38-220-530 Small-Sized Standing Seam Roofing Machines With Adjustment are as follows:

Features:
(1). Minitype Figure;
(2). Easy to set and to operate;
(3). Forming Steps: 8 steps

Main Accessories:
(1). Main Standing Seam Roofing Machines;
(2). 3 Tons Manual Uncoiler;
(3). PLC Computer Controlling System for Counting (Brand: Delta from Taiwan);
(4). Hydraulic System;
(5). Device for adjusting variable wieth;
(6). Hydraulic Forming Cutter;
(7). Run out table (3 PCS);
(8). Protective Cover;
(9). Tools;
(10). Operation Manual.

Usage: Producing standing seam roofing panels.

1.	Size	2000*1100*1200mm
2.	Weight	1500KGS
3.	Motor Power	2.2KW
4.	Power for hydraulic forming cutter	0.75KW
5.	Voltage	380V/50HZ/3PH
6.	Forming Steps	8  steps
7.	Forming Speed	6-8m/min
8.	Thickness for Steel	0.5-0.8mm
9.	Height of Roofing	38mm
10.	Effective Width for Roofing	220-530mm
