• Model NO.：WD-1516-ZZ22
• HS Code：8479811000
• Production Capacity：100PCS,Year

Basic Info.

Model NO. WD-1516-ZZ22 HS Code 8479811000 Production Capacity 100PCS/Year

Product Description

Middle forming machine is consisted of machine framework, hydraulic power system, control system, and forming tooling system. Powered by hydraulic system, machine drives the forming tooling system, so as to control the expansion and shrink of expansion blade and forming blade to complete the stator coil forming.

Application
This type of machine is suitable for AC motor, induction motor stators, and 3 phase motor , fan motor, compression motor ,air conditioner motor, washing machine motor,  generator motor and pump motor.

Feature
High quality level of the forming process
Manual loading and unloading
Hydraulic driven, PLC control
Can be customized accordingly
Integrable in a production line
No need to change tooling for different stack length, only mechanical adjustment required

Specification

Item	hydraulic forming	servo motor forming
Size	1000x1400x3000mm	1000x1700x3000mm
Tooling included weight	about 550KG	about 550kgs
Power supply	380V/50Hz 3 phase four wires, 3.75KW	380V/50Hz 3 phases four wires, 3.75KW
Working pitch time	≤13S/PC	≤13S/PC
ID	Min 30mm	Min 30mm
OD	Max 210mm	Max 210mm
Core length	20-200mm	20-200mm
