• Model NO.：HT2000
• Wire Diameter：0.8-2.5mm
• Welding Width：600-2000mm
• Rated Capacity：65kvax4
• Dimensions：3350X1800X1400mm
• Certification：ISO9001
• Transport Package：Plastic Bag, Also Can Made as Your Request
• Specification：wire diameter: 0.8-2.5mm
• Trademark：hengtai
• Origin：China
• HS Code：8463300000
• Production Capacity：15 Sets,Month

Size of mesh (mm)
12.7-101.6 (1/2"-4")
Width (mm)
914.4-1219.2 ( 12"-48")
Diameter of wire (mm)
Dia.0.63-Dia.2 ( BWG23-BWG14)
Max. rolled net size (mm)
120 (400')
Welding speed ( mesh/minute)
65 ( radia)
Power
380/220V
50-60HZ
50KWAx4
Outside size(mm)
2600x1700x1350

Peculiarity: Big box-style support, high stability, lower noise, E-Machine in one, straighten & send wire automatically. Used for welded wire mesh of big width & wire dia.
Size of mesh (mm)
25.4-152.4 (1"-6")
Width (mm)
1219.2,1524,1828.8 (48", 60", 72")
Diameter of wire (mm)
Dia.1.07-Dia.2 ( BWG19-BWG14)
Max. rolled net size (mm)
91.4m (300')
Welding speed ( mesh/minute)
45 ( radia)
Power
380/220V;50-60HZ;50KWAx6
Outside size(mm)
3350x1800x1400
Peculiarity: Shuttle sending weft wire type, sending quicker, lower noise, more stable, save electricity. Used for welding net of wire diameter 0.45, diameter 1.07, mesh 1/4" -1/2".
Size of mesh (mm)
6.35-12.7 (1/4"-1/2")
Width (mm)
914.4-1219.2 (12"-48")
Diameter of wire (mm)
Dia.0.45-Dia.1.07 ( BWG25-BWG19)
Max. rolled net size (mm)
120m (400')
Welding speed ( mesh/minute)
75 ( radia)
Power
380/220V;50-60HZ;50KWAx4
Outside size(mm)
2350x1820x1700






Specification

Light Full Automatic welded wire mesh machine (In Roll)


Welding wire diameter

Φ0.4-Φ1.2(mm)

                   Mesh size

                       1/4''-4''

                  Mesh width

                     600-2100(mm)

Welding speed

80-120 times / min

Nominal Power

85KVAX6

Voltage

380v--415V  3 phase 50HZ

Dimension

2500×1500×1200 (mm)

Machine weight

2600kg



Welding wire diameter

Φ0.8-Φ2.5(mm)

Mesh size

1''-4''

Mesh width

914-2100(mm)

Welding speed

60-90 times / min

Nominal Power

80KVAX5

Voltage

380v--415V  3 phase 50HZ

Dimension

3100×1700×1400 (mm)

Machine weight

3500kg

 UsageProduct Description

We produce exclusive range of welding mesh machine, which is widely appreciated among our customers due to its reliable and efficient performance. It is ergonomically designed in accordance with international quality standards, so that to deliver a faultless product range to our clients.

Contact Us

We can supply different types of wire mesh making machines.



Buying Guides

Dear sir/madam, if you are intrested in our machines, you can inquiry me with Product parameters as following, and I will give you the  reasonable price.

1. Wire diameter: from____to____mm ( adjustable )
2. Mesh Size: from____to____ mm²   ( adjustable )
3. Mesh width: 1000mm  1200mm  1500mm  1800 mm ( Or customized )
4. Industrial voltage : ________380V or 220V , 3 phase 50HZ ( Or customized )
5. Other requirements: .________



Our machine is popular in India, United state,Pakistan,Kenya,Egypt,Russia,Uzbekistan,Mexico, Brazil, Australia, Thailand, Korea, Saudi Arabia, Morocco, Algeria,etc.



24 hours after sales service

Technical assistance

Adjustable mesh width

Keep safety of operator
