• Trademark：CUSTOMIZED
• Origin：Qingdao
• HS Code：8466200000
• Production Capacity：3000PCS Per Year

CuttingSwing over bed.............................................................140mmDistance between centers.................................................250mmHole through spindleSpindle taper...............................................................MT2Tailstock taper............................................................MT1Spindle speed...................................100~2000rpm±10%Range of the threads     Metric.............0.5~1.25mm(5 thread pitches)                                or    Imperial..................16~24TPI (5 thread pitches)Drilling and millingMax.drilling/milling capacity.............................................10mmTravel of drilling/milling sp..............................................30mmDrilling/milling spindle speed...........................100~1500rpm±10%T-slot.....................................................................8mmOutpower.............................................................150WNet/Gross weight.................................................40/57kgPacking size.....................................................690x430x615mmCuttingSwing over bed.......................................................250mmDistance between centers......................................550mmHole through spindle...............................................20mmSpindle taper.......................................................MT3Tailstock taper.....................................................MT2Spindle speed....................................125~2000rpmOutput power......................................................550WRange of the threads     Metric.............0.4~3.0mm(12 thread pitches)                               or    Imperial..................10~44TPI (8 thread pitches)Drilling and millingDrilling capacity................................................13mmEnd milling capacity...........................................16mmFace milling capacity............................................30mmDrilling & milling spindle taper...................................MT3Spindle speed     Low................................0~1100rpm                              High...................0~2500rpmOutput power.................................................350WT-slot..................................12mmSpindle rotary angle................................-25~+45Packing size..................................810x420x500mm
