Digital Optical Comparator Measurement Machine, Optical Profile Projector Cpj-3000 Series
Laizhou Laihua Testing Instrument Factory- After-sales Service：Technical Guidance
- Condition：New
- Certification：CE
- Standard：ASTM
- Customized：Non-Customized
- Material：Stainless Steel
Base Info
- Model NO.：3015
- Transport Package：Wooden
- Specification：600*950*1000
- Trademark：Laihua
- Origin：China
- Production Capacity：1 Set
Description
ModelCPJ-3020W CPJ-4025W X-axis Travel (mm) 200 250 Y-axis Travel (mm) 100 150 Worktable size (mm) 400×150 450×200 Swing range ±15° ±15° ( can be custom made to ±25°) Resolution (μm) 0.5 Indication error (mm) X, Y-axis: (2.5+L/100). Z-axis: 3.5+L/50 (L is the length of the measured object. Unit: mm) Z-axis Travel (mm) 75 (focusing) 100 (focusing) Weight (kg) 160 240 Dimension (mm) 1090×830×1010 1215×646×1210 Projector screen Size (mm) Ф 300 Ф 400 Rotary range 0~360° Resolution 1' or 0.01° Lens (CPJ-3020W) Magnification 10× (Optional) 20× (Optional) 50× (Optional) 100× (Optional) Field of view (mm) Ф30 Ф15 Ф6 Ф3 Working distance (mm) 77.7 44.3 38.4 25.3 Lens (CPJ-4025W) Magnification 5× (Optional) 10× (Standard) 20× (Optional) 50× (Optional) 100× (Optional) Field of view (mm) Ф80 Ф40 Ф20 Ф8 Ф4 Working distance (mm) 93.7 103.9 95.1 65.7 35.0 Data processing system Multi-functional DRO DC-3000 Illumination Transmission: 24V/150W halogen lamp. Reflection: 21V/150W halogen lamp. Accessories Printer, edge detector, Measuring software M2D-CPJ, etc. Power supply: AC 100-240V 50/60Hz. Total power: 450W
Packaging and shipping
Packaging: Standard export package, wooden case
Delivery: 3 days upon receipt of payment, depend on order quantity
Company Information:
Laizhou LaiHua Testing Instrument Factory was founded in 2010,which specializes in the manufacture of hardness testers and metallographic equipments for metaland nonmetal materials. Besides, we can also design special, large-scale dedicated machines according to the requirements of customers.
