Cut to Length Roof Roll Forming Machine Roof Sheet Roll Forming Equipment Set
Zhangjiagang City Zhangyun Machinery Manufacturing Co., Ltd.- Automatic Grade：Automatic
- Warranty：1 Year
- Certification：ISO, CE
- Transport Package：Wooden
- Specification：Uncertain
- Trademark：ZHANG YUN
Base Info
- Origin：Jiangsu, China
Description
Main Forming EngineThe mechanical spreading width 550mm Arch material HT200, tempered. The columm cross-section size 80*70, with sufficient strength and reliable quality assurance. Roller diameter of vertical guiding roller 80 Material 40Cr steel, quenched and tempered. Bearing type Fixed surface 7216, regulation 32216, each has 4. Gear box material HT200 Host power 45KW r, electromagnetic speed regulating Speed reducer ZQ650 Speed ratio 48.57
The equipment total power is 78.9Kw, with 30000mm*4000mm length*width. The maximum rolling height is 85mm, the maximum rolling thickness is 4.0mm, and the maximum rolling speed is 3~12m/min. Structural materials of welding machine seat must meet the requirements, welding must be up to the national standard. Equipment after rust cleaning should be firstly coated with steel special anti-rust paint comprehensively covering, and then coated with high quality topcoat. The rotating part should be divided by warning color.
The equipment total power is 78.9Kw, with 30000mm*4000mm length*width. The maximum rolling height is 85mm, the maximum rolling thickness is 4.0mm, and the maximum rolling speed is 3~12m/min. Structural materials of welding machine seat must meet the requirements, welding must be up to the national standard. Equipment after rust cleaning should be firstly coated with steel special anti-rust paint comprehensively covering, and then coated with high quality topcoat. The rotating part should be divided by warning color.
