• Model NO.：Z110, 140, 180, 270
• Transport Package：in The Container
• Specification：6tons
• Trademark：XHH
• Origin：Xiamen City, Fujian Province, China
• Production Capacity：15sets,Month

Basic Info.

Model NO. Z110, 140, 180, 270 Transport Package in The Container Specification 6tons Trademark XHH Origin Xiamen City, Fujian Province, China Production Capacity 15sets/Month

Product Description

The informaitons of Z110, 140, 180, 270 Purline Forming Machines with Pre-punching are as follows:

1. Forming Speed: 10-14m/min;
2. Forming Thickness: 2.0-3.0mm.

Main Accessories:
(1) Main Purline Forming Machine;
(2) 5 Tons Hydraulic Un-coiler;
(3) Automatic Guide Device;
(4) Hydraulic Motor System ( there are total three oil cylinders, two for punching holes, one for pre-cutter)
(5) PLC Computer Controlling System with Touching Screen (Brand: Delta Made in Taiwan, or Schneider, or Siemens);
(6) Pre-punching Holes Device( the buyer decide the size of punching holes );
(7) Pre-cutting Device;
(8) Reshaping Device;
(9) PLC Automatic Controlling System For Adjusting Size From 60mm to 300mm; PLC Automatic Controlling System For interchange C to Z Purline;
(11) Run Out Table(4 PCS);
(12) Tools;
(13) Operation Manual.

Material normal galvanized building coils
Usage Purline for steel structure of building projects

Feature: One c purline machine can be automatically adjusted and produced any models of purlines from 80mm to 250mm in three minutes.

1.	Size	8500*1500*1400mm
2.	Weight	7500KGS
3.	Hydraulic Motor Power	22KW
4.	Voltage	380V/60HZ/3PH
5.	Forming Steps	13 steps+3 steps for reshaping
6.	Forming Speed	10-14m/min
7.	Forming Thickness	2.0-3.0mm
8.	Thickness for common use and test	2.0mm, 3.0mm(Material: Galvanized Steel)
9.	Height of Z Purline	40mm, 45mm, 55mm, 60mm
10.	Lip of Z Purline	15mm, 20mm
11.	Width of Z Purline	110mm, 140mm, 180mm, 270mm
12.	Material Width	200mm, 240mm, 300mm, 270mm
