Kgps Series Medium Frequency Induchion Melting Equipent for Smelting and Casting
Guangzhou DuroWelder Limited- Control Type：SCR
- Customized：Customized
- Condition：New
- Automatic Grade：Semi-Automatic
- Certification：CE, RoHS, GS, ISO9001
- Type：Special Casting
Base Info
- Model NO.：KGPS Series
- 0utput Voltage：750V-3300V
- Melting Speet：0.06t,H-30t,H
- Melted Metal Material Type：for Steel, Copper, Al.
- Transport Package：Wooden Case
- Specification：depends
- Trademark：DuroWelder
- Origin：Gangdong, Chine
- HS Code：8514400090
- Production Capacity：30 Sets,Month
Description
Model No.
Furnace
Capacity
Rated Power
Working Frequency
Input Voltage
Output
Voltage
Melting Speed
Power Consumption
Cooling Water Flow Rate
Melted Metal Material Type
KGPS-Fe-0.02T-30KW
0.02T
30KW
1-4KHZ
380-415V
750V
0.06T/H
650KWH/T
5T/H
For Melting Various Steel Material
KGPS-Fe-0.05T-50KW
0.05T
50KW
1-4KHZ
380-415V
750V
0.14T/H
650KWH/T
5T/H
KGPS-Fe-0.35T-250KW
0.35T
250KW
1-2.5KHZ
380-415V
750V
0.55T/H
620KWH/T
15T/H
KGPS-Fe-5T-3.6KKW
5.0T
3.6KKW
0.50KHZ
1000V
1650V
6.T/H
550KWH/T
60T/H
KGPS-Fe-50T-30KKW
50T
30KKW
0.15KHZ
1000V
1650V
30.T/H
420KWH/T
450T/H
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Model No.
Furnace
Capacity
Rated Power
Working Frequency
Input Voltage
Output
Voltage
Melting Speed
Power Consumption
Cooling Water Flow Rate
Melted Metal Material Type
KGPS-Cu-0.15T-100KW
0.15T
100KW
1KHZ
380-415V
750V
0.18T/H
390KWH/T
2.5T/H
For Melting Various Copper Material
KGPS-Cu-0.50T-250KW
0.50T
250KW
1KHZ
380-415V
1500V
0.50T/H
380KWH/T
7.5T/H
KGPS-Cu-10T-5.0KKW
10.T
5.0KKW
0.25KHZ
950V
3300V
12T/H
340KWH/T
55T/H
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Model No.
Furnace
Capacity
Rated Power
Working Frequency
Input Voltage
Output
Voltage
Melting Speed
Power Consumption
Cooling Water Flow Rate
Melted Metal Material Type
KGPS-Al-0.05T-50KW
0.05T
50KW
1KHZ
380V
750V
0.15T/H
630KWH/T
4.5T/H
For Melting Various Al Material.
(Can also melt zinc,consume power 50% less.)
KGPS-Al-0.10T-80KW
0.10T
80KW
1KHZ
380V
750V
0.25T/H
630KWH/T
5.5T/H
KGPS-Al-3.00T-1.5KKW
3.00T
1.5KKW
0.5KHZ
720V
2500V
4.00T/H
490KWH/T
35T/H
