Steel Straightening Machine

Wuxi Datang Welding & Cutting Mechanical Equipment Co., Ltd.
  • Type:or H-Beam
  • Usage:H Beam Flange
  • Voltage:220-575V
  • Automatic Grade:Semiautomatic
  • Principle:Mechanical
  • Certification:CE

Base Info

  • Model NO.:HYJ
  • Warranty:24 Months
  • Customized:Customized
  • Condition:New
  • for Thickness:Max 40mm
  • Transport Package:Container
  • Specification:Standard
  • Trademark:Datang
  • Origin:China
  • HS Code:84622910
  • Production Capacity:50 Sets Per Month

Description

Basic Info.

Model NO. HYJ Warranty 24 Months Customized Customized Condition New for Thickness Max 40mm Transport Package Container Specification Standard Trademark Datang Origin China HS Code 84622910 Production Capacity 50 Sets Per Month

Product Description

H Beam Flange Straightening Machine

This machine is the special equipment, which is mainly used for the flange plate distortion straightening.

It includes mechanical and hydraulic two series for the customers' selection. Mechanical type straightening machine with simple structure, covenience operation and reliable ability; Hydraulic type straightening machine with the large straightening capability, wide straightening range, high automatic degree, which is the first developed in domestic market.

The straightening roller and powered roller is adopted good alloy steel with advanced heattreatment technology to ensure the long term runing.



Hydraulic type straightening machine is used for the angle distortion straightening of the H-beam with large thickness. Hydraulic cylinder presses from down side to up side, which has strong force and high driving torque and with good straightening efficiency and good quality. This machine is widely used for the fire electric furnace, heavy duty steel structure construction, steel bridge, water power industry etc.
ModelHYJ-800
Flange width(mm)200-800
Flange thickness (mm)≤40
Web plate minimum height (mm)350
MaterialQ235A
Straightening speed (m/min)18
Power(Kw)25
Size (mm)3500*1500*1700
