PU Sandwich Roof Wall Panel Forming Machine with ISO

Hangzhou Zhongyuan Machinery Factory
  • Type：Rolling Machine
  • Forging Forming Method：Roll Forming
  • Power Source：Electric
  • Feature：Automation
  • Certification：ISO9001, CE
  • Warranty：12 Months

Base Info

  • Model NO.：ZYYX
  • Customized：Customized
  • Advantage：Use Widely
  • Condition：New
  • Machine Color：Made-to-Order
  • Original Brand Name：Zhongyuan
  • Control Mode：Mitsubishi PLC & Converter
  • Place of Origin：China
  • Transport Package：About Ten 40 Containers
  • Specification：CE SGS BV
  • Trademark：zhongyuan
  • Origin：China
  • HS Code：84552210
  • Production Capacity：3sets , Year

Description


Sandwich Panel Spec
 Panel width               1000mmPanel thicknessMini thickness:
40mm (corrugated sandwich panel)
50mm (wall panel)Max. thickness:
150mm (corrugated sandwich panel)
200mm (wall panel)Steel Sheet Spec (we can design as per buyer's special requirement )Thickness0.4-0.7mm color steel sheetWidth1250mmMax. coil weight5tonsInner Dia. of coil508mm
Whole Line Spec
 Working speed 3-7m/min (adjustable)Total lengthabout 120mDouble belt conveyor23mControl modeMisubishi PLCPouring pressure150-200BarWork height1200mmStacking height1000mmTotal powerabout 100KwPower required 380V/3phase/50Hz or as per customers requirement
Components
 Hydraulic Uncoiller2Platform for forming machine1Roll Forming System2 setsFoaming system1Double Belt Laminator1Cutting System1Stacking system1
