• Model NO.：XM-B38NC
• Bending Angle：0-1900
• Transport Package：Seaworthy Package
• Specification：depends on different model
• Trademark：Rainbow
• Origin：China

Basic Info.

Model NO. XM-B38NC Bending Angle 0-1900 Transport Package Seaworthy Package Specification depends on different model Trademark Rainbow Origin China

Product Description

Machine Description

XM-B38NC hydraulic pipe bending machine

 main technical parameters:
1,  maximum bending capacity: Φ 38 * 2.0 (carbon steel, for example)
2,  bending radius: Only one kind of bend radius. Bending radius: R35 ~ R350
3,  bending angle: 0-1900
4, through the core effective length: 2350mm
5, the control power supply: AC220V (AC contactor) DC24V (solenoid valve proximity switch)
6, the bending speed: Max 440 / s
7, clamping stroke: 51mm
8, given the tight itinerary: 51mm
9, motor power: 5HP
10, pump displacement: 17L / min (NB2-D20F)
11, maximum system pressure: 12MPa
12. Fuel tank capacity: 190L (using 68 hydraulic oils)
13, the machine appearance: 2400 * 700 * 1000
14. Weight: 900KG.
15, the angle setting: 16 kinds.

Company Profile

Our company comes from China National Machinery Import and Export Corp. Harbin branch. By many years market development and experience accumulation,now we have became the biggest Chinese fastener equipment dealer and turnkey consultants of fasteners manufacturing project for abroad customers.

  We are supplying high quality and reliable machines for the entire fastener industry with our professional and timely after sale service,our main products include wire drawing machine,Bolt Maker, Nut Maker, Part Former, Heading Machine, Thread Rolling Machine and Mesh Belt Furnace.

  With our business reputation and professionalism, our company has experienced a significant growth in business during the recent years and we invested in some fastener equipment manufacturers and built our own bolt maker,mesh belt furnace and zinc plating line factories.We do these factories' foreign market developing and have received highly praises from a lot of customers.

  We have established reputation in countries such as India, US, Europe and Southeast Asia where we have core customer bases. Meanwhile, we are well respected by the domestic factories and the customers in the mechanical and electrical business.
