Guide Rail Roll Forming Machine Yx21-41

Zhangjiagang City Saibo Science & Technology Co., Ltd.
  • Type：Rolling Machine
  • Forging Forming Method：Mold Forging
  • Power Source：Electric
  • Feature：High Efficiency
  • Certification：ISO9001, CE
  • Warranty：12 Months

Base Info

  • Model NO.：Yx21-41
  • Customized：Customized
  • Advantage：Easy to Maintenance
  • Condition：New
  • Product Name：Yx21-41 Guide Rail Roll Forming Machine
  • Thickness：1.2-1.5mm
  • Roller Stations：22 Stations
  • Transport Package：Sea Packing
  • Trademark：SAIBO
  • Origin：Jiangsu, China
  • HS Code：84552210
  • Production Capacity：300set,Year

Description

 No Description Specification Request1.Roll forming machineYX21-41 1.2Rolling speed0-15m/min(not include cutting time)
  1.3Rolling thickness1.2-1.5mm 1.4MaterialGI
  1.6Un coiler3 TON manual un-coiler
  1.7The material widthBase on the final profile
  1.8Roller stations22 stations( base on final design)
  1.9Leveling stations7 stations
  1.10Punching machine63T pneumatic punching machine
  1.11Roller materialCR12, 58-62,HRC hardness and chrome plated surface 1.12Shaft diameter45# forge steel ¢120mm 1.13Maim motor power11kw X 2 1.14Hydraulic station power15KW 1.15Hydraulic pressure25Mpa 1.16Material of cuttingCr12 with heat treatment 58-60°
  1.17Tolerance3m+-1.5mm 1.18Electric source380V, 50HZ,3 phase 1.19Way of driveBy china 1.20Color of the machineYellow and blue
