High Quality Auto Parts Flat Engraving DOT Pin Marking Machine
Perfect Laser (Wuhan) Co., Ltd.- Carving Material：All Metals and Some Nonmetals
- Controlling Mode：CNC
- Main Axle Rotational Speed：≤30000rpm
- Milling Cutter Diameter：3mm
- Feeding Height：>300mm
- Certification：ISO9001, CE
Base Info
- Model NO.：PEQD-025
- Warranty：12 Months
- Customized：Customized
- Condition：New
- Machine Name：DOT Peen Marking Machine
- Machine Type：Portable Type
- Marking Depth：0.01~2mm
- Marking Accuracy：0.01 mm
- Pin Hardness：HRC 73
- Power Supply：220V 50Hz
- Air Pressure：0.2-0.6 MPa
- Machine Power：<=400 W
- Motor：Step Motor
- Valve：USA Imported Mac Brand High Frequency Valve
- Transport Package：Wooden Case
- Specification：ISO9000 & CE
- Trademark：Perfect Laser
- Origin：China
- HS Code：8479819000
- Production Capacity：500 Units, Month
Description
-5~40 ºC Whole Machine Weight 60 Kgs 75 kgs 45kgs
Auto Parts Flat Engraving Dot Pin Marking Machine Configuration
1. Marking System: Moves on the Imported Linear Guild Rail, Automatically Lubricate, Air-Proof, Dust-Proof.
2. XY 2D Moving System: Adopt Imported Linear Guide Rail, Smooth & Fast Moving.
3. Stepper Motor: High Stable Performance, Ensure High Precision.
4. Synchronous Belt: Accurate transmission, Long life time, Improve the working efficiency.
5. USA Imported High-frequency Valve: Using time can reach 0.1-0.2 billion times.
6. Absorbing System: Can heavily absorb in large work pieces, enable precise marking.
7. Marking Pinhead: Made by Imported Hard Alloy, precision mould and molding, Rigidity can reach 92 HRA.
8. Marking Head Cover: Compact structure, Beautiful Design, Dust-proof, Water- proof.
9. Marking switch: Convenient designed, Just press it for marking, No need operate on PC.
10. Control Box: Integration design, Small size, Simplify structure.
Company information
We, Perfect Laser, As a 21 years history industrial equipment manufacture in laser field, 12 year Golden Supplier in Alibaba, with CE/ISO/FDA, we aims to make high quality products, and also our products have been exported to more than 180 different countries and areas.
FAQ
Q1.: What's the package?
A: We have 3 layers package. For the outside, we adopt wood craft case. In the middle, the machine is covered by foam, to protect the machine from shaking. For the inside layer, the machine is covered by thickening plastic bag for waterproof.
Q2.: Will the package damaged during transportation?
A: Our package is considerate all the damage factors and make it to be safe, and our shipping agent have full experienced in safe tranportation. We have exported to 180 countries worldwide. So please don't worry, you will receive the parcel in good condition.
Q3.: How to install and run the machine?
A: Our technician have installed the machine before shipping. For some small parts installation, we will send detail training video, user's manual along with the machine. 95% customers can learn by themselves.
Q4.: How can I do if the machine goes wrong?
A: If confronted with such problems, please contact us asap and do not try fix the machine by yourself or someone else. We will response within 24 hours as quick as we can to solve it for you.
Contact us
Conatct Person:Sally / sales department
Tel:0086-18062623851
Fax:0086-2786775865
