• Model NO.：CNC341S
• Trademark：LEAD
• Origin：China
• HS Code：8456301090
• Production Capacity：40 Sets,Month

Basic Info.

Model NO. CNC341S Trademark LEAD Origin China HS Code 8456301090 Production Capacity 40 Sets/Month

Product Description

Three axes employ roller and ball type linear ways, exhibiting outstanding structural rigidity and machining stability. Three axes are transmitted by C5 grade precision ball screws and equipped with 1 µ Differential type precision linear scales and provide closed loop control. Applying Laser interferometer inspections during assembling. Mirror Finish circuit is equipped as standard. Special circuit design for fast cutting tungsten carbide is available.

Main Unit Features:

1. The structural parts are designed and analyzed by applying the advanced Finite Element Analysis(FEA).
2. Precision linear ways on all axis assures smooth movement and high accuracy.
3. All structural casting are made of FC-30 cast iron, tempered and stress relieved for deformation free performance.
4. High precision spindle assembly insures excellent eroding performance.
5. Table surface is hardened and precision ground, assuring high machining accuracy and long service life.
6. Three axes movements are transmitted by precision ball screws.
7. Three axes are driven by DC servo motor.
8. Three axes are equipped with 1 µ Linear scale for closed loop control.
9. Each machine is compensated by laser interferometer, ensuring position reliability and increasing machine efficiency.

Specification for machine unit:

Model	Unit	CNC-341S
Table travel(X axis)	mm	400
Table travel(Y axis)	mm	300
Quill travel(Z1 axis)	mm	260
Work head travel(Z2 axis)	mm	210
Work table dimensions(LxW)	mm	650x400
Distance between plate and table	mm	195-625
Work tank inner dimensions(WxDxH)	mm	1066x560x424
Max. capacity of dielectric fluid	Liter	400
Max. electrode weight	kg	75
Max. workpiece weight	kg	1000
Machine unit dimensions(WxDxH)	mm	1210x1300x2150
Machine unit weight	kg	950
