Metallic Processing Machinery

PC Bar Production Line for Railway Sleeper PC Bar Induction Heating Line

Hangzhou Suntech Machinery Co., Ltd.
  • Automatic Grade:Automatic
  • Warranty:1 Year
  • Certification:GS, RoHS, ISO, CE
  • Transport Package:Seaworthy Packing
  • Specification:7mm-13mm
  • Trademark:SUNTECHMACH

Base Info

  • Origin:China
  • HS Code:846330
  • Production Capacity:500 Sets,Year

Description

No.

Item

Specification

1

Raw material

30MnSi,30Si2Mn and other alloy spring steels

2

Diameter

Φ 7.0-13.0mm

3

Working speed

90-100m/min for type φ 7.1mm;

80-90m / min for type  φ9.0mm;

65-70m/min for type φ 10.7mm;

40-45m/min for type φ 12.6mm.

4

Induction quenching temp.

≤950ºC constant and adjustable

5

Induction tempering temp.

≤450ºC constant and adjustable

6

Temp. control accuracy

≤ ±5ºC

7

Take-up coil dimension

φ1800-φ2400mm

8

Pay-off

Horizontal rotating type pay off

9

Center elevation

1000mm

10

Production method

Continuous production

11

Finished products

1) Products keep consistence with "GBT5223.3-2005" and "JISG3137-1994"


III. Details of machine for reference:
PC Bar Production Line for Railway Sleeper PC Bar Induction Heating Line

PC Bar Production Line for Railway Sleeper PC Bar Induction Heating Line

PC Bar Production Line for Railway Sleeper PC Bar Induction Heating Line


IV. Our Workshop:
PC Bar Production Line for Railway Sleeper PC Bar Induction Heating Line

PC Bar Production Line for Railway Sleeper PC Bar Induction Heating Line

PC Bar Production Line for Railway Sleeper PC Bar Induction Heating Line




V. Clients list for reference:
PC Bar Production Line for Railway Sleeper PC Bar Induction Heating Line
