China CNC Table Plasma Cutting Machine for Metal Sheet Cutter Price 1325/1530/2030
SHANDONG IGOLDEN CNC TECHNOLOGY CO., LTD.- Customized：Non-Customized
- Layout：Coaxial
- Cutting Material：Copper, Carbon Steel, Iron, Aluminum, Stainless Steel
- Automatic Grade：Automatic
- Power Source：Electric
- Cutting Mode：Plasma Cutting
Base Info
- Transport Package：Wooden Box
- Specification：3500*2250*1500mm
- Trademark：IGOLDENCNC
- Origin：Jinan, China
- HS Code：8456401000
- Production Capacity：200 Sets,Month
Description
Effective Cutting Width (X axis)
1300mm (optional)
Effective Cutting Length (Y axis)
2500mm (optional)
Motor Mode
Stepper (or Servo)
Transmission
High quality helical rack
Lifting body
1set
Plasma torch
1set
File transmission
USB transmission
Cutting shape
Steel plate and rotary for steel tube
Software
Fastcam software with Nesting function
Plasma power source
Huayuan (63A 100A 120A 160A 200A)
(Hypertherm 45A 65A 85A 105A 125A 200A)
Cutting thickness
20MM MS, 10MM SS
Height regulating device
Arc voltage height
Cutting speed
Depens on metal and thickness
Cutting precision
±0.3mm
Control ccuracy
±0.01mm
Support software
Fastcam /Type3/autocad/pro/CAXA etc.
Working Temperature
-5~60°CRelative Humidity, 0-95%.
Power Supply Voltage
380V±20%(220V optional,but we need custom for you)
Packing Weight
1600kg
Packing Size
3300x2200x1500mm
