Common Nail/Staple/Roofing Nail Making Machine

Wuxi Wandeshun Machine Co., Ltd.
  • Type：LW Pulley Type Metal Drawing Machine
  • Usage：Wire
  • Metal Material：Steel
  • Outlet Diameter：0.5-4.5mm
  • Max.Inlet Wire Dia.：6.5mm
  • Block Dia.：560mm

Base Info

  • Max. Number of Block：12
  • Certification：ISO
  • Condition：New
  • Power(W)：18.5kw
  • After-Sales Service：Engineers Available
  • Quality：Korea Quality Europe Quality
  • Main Market：Asia, Afria, South America
  • Voltage：380,415,440,220
  • Warranty：One Year
  • Dimension(L*W*H)：as Design
  • Drawing Material：High Carbon, Low Carbon and So on
  • Transport Package：PE
  • Specification：weight 8 ton
  • Trademark：wandeshun
  • Origin：China
  • HS Code：8463102000
  • Production Capacity：1000 Set One Year

Description

SPECIFICATIONS FOR OTO/PULLEY WIRE DRAWING MACHINEITEMSUNITLW1-9/650(700)LW1-9/560(600)LW1-9/450(400)Capstan diametermm650, 700560, 600450, 400Inlet wire diametermmΦ8.0-Φ6.5Φ7.0-Φ5.5Φ3.0-Φ2.5Min outlet wire diametermmΦ2.0Φ1.6Φ0.7Inlet wire tensile strengthMpa400-1200400-1200400-1200Drawing speedm/min<=240<=360<=720Drawing diestime1-91-91-9Total reduction rate%<=90.53<=91.52<=92.16Motor powerKw37-18.530-18.515-7.5
