• Model NO.：DN100
• Outer Dimensions：15000*1100*1700
• Packing Details：Polywood Box and Standard Pallet
• Transport Package：Standard Seaworthy Package
• Specification：SGS
• Trademark：HLT
• Origin：China Jiangsu
• HS Code：844790900
• Production Capacity：500,Year

ID
DN50
DN65
DN80
DN100
DN125
DN150
DN200
DN250
DN300
Single wall thickness
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.2
1.5
Double layer wall thickness
0.25*2
0.3*2
0.4*2
0.50X2
0.60X2
0.70X2
0.80X2
0.90X2
1.0X2
The parts will go with the machines: The molds for DN50,65,80,100,125, 150,200,250,300mm

5.DN200-630 Hydraulic Forming Machine
Diameter: DN200-630mm
No. of layers: single or double layers
Wall thickness: Single layer1.0-3.0mm
Double layers:0.8*2-1.6*2
Type of the bellows: annular bellows
Control: PLC control, manual or automatic control
Straight tube length: ≤1800mm
Expanding medium: emulsified liquid
Forming speed:8-28seconds per convolution
Molds and water injection head: DN200,250, 300,350,400,450,500,550,600mm
Hydraulic Hose Making MachineMachine Type No.HLT-H-150Technical DataApplication of the hose: water, oil, steam
Size range: DN32 up to DN150
Wall thickness: 0.2-0.3mm
Production speed:2.5~3.5m/min
Strip thickness: 0.18-0.3mm
Material: sus304, 321 and 316L
Outer dimensions:15000*1100*1700Packing detailsPlywood box and standard palletMOQ1 setWarranty1 yearPayment termsT/T, L/C, D/P, Western union
Company information

We are professional manufacturer of all types of metal flexible metal hose and machinery, such as corrugated metal hose, square lock and interlock hose/ conduit with more than 25 years of experience. The hoses are widely used in many industries: gas hose, water hose and wire & cable protection circuit, etc..
The sizes are as follows:
Square lock hose and machinery:ID6-ID103
Interlock hose and machinery:ID3-ID350mm on different machine
Annular and corrugated metal hose: ID8 till ID600 on different machine


Our service
 Warranty period of one year
 standard seaworthy package
 Engineers available to service machinery oversea


FAQ for hose making machine
Q: Why choose us for metal hose forming machine?
A: We are most professional manufacturer of hose making machine with more than 25 years of experience
Q: What size can you make?
A: All the sizes from DN8 up to DN400 can be made on different machines
Q: How many different types of machine can you make?
A: Hydraulic metal hose forming machine
  a:DN16-65mm   b:DN25-DN100mm   c:DN32-150mm  d:DN50-300mm  e:DN80-400mm
B: Mechanical hose making machine
  DN8-50mm
C:PU/ Elastomer Metal Hose Making Machine
 a:DN12-100   b: DN50-150   c:DN12-65
Q:Can the hose forming machine be used for bellow making?
Yes, all above hose forming machine can be used for bellow making as well

We need to know following information to quote you correct machineries:
1.Size range you want to make
2.The application of the hose you need, for instance, natural gas hose, water hose, air conditional hose, etc..
3.Wall thickness
