• Model NO.：DN8~DN32
• Material of Strip：SUS304, 321 and 316L
• Application：Gas Hose,Water,Hose ,AC Hose
• Packing Details：Plywood Box and Standard Pallet
• Transport Package：Standard Seaworthy Package Plywood Box
• Specification：SGS
• Trademark：HLT
• Origin：Jiangsu China
• HS Code：844790900
• Production Capacity：400sets,Year

No.
Size
Tube OD
(mm)
Wall thickness
(mm)
Hose ID
(mm)
Hose OD
(mm)
Pitch
 distance
(mm)
Width of the strip
(mm)
1
DN 8
10.3
0.18
8
11.3
2.7
31.8
2
DN10
12.3
0.18
10
13.5
2.9
38.1
2
DN 12
15
0.18
12.3
16.3
3.2
46.6
3
DN 16
20
0.2
16.2
21.3
4.5
62.2
4
DN 20
23.5
0.25
20
25
4.5
73.0
5
DN 25
30
0.3
25
31.5
4.5
93.3
6
DN 32
39.5
0.3
33
41
4.5
123.2

Testing bench
The machine is widely used for following hose testing:
water hose, gas hose, solar hose and fire fighting hose hydraulic leakage testing
Size range:DN8-32mm
Pressure:6bar
Max. length of the hose: up to 2000mm
No. of hoses testing at the same time: 4-8pcs
Testing medium: water



Vertical fitting welding machine
Size range: DN8-32
Welding type: TIG welding
Welding position: circumferential seam welding
Compact structure
Torch Automatic rotating


Hose compressing machine
To get more flexible hose, the metal hose will be compressed on this month, the pitch distance will be closed which make hoses more flexible.
Application: vacuum hose/bellow, high flexible bellows
Size range: HJ-BA100 DN25-100mm
HJ-BA200 DN100-200mm


Company information

We are professional manufacturer of all types of metal flexible metal hose and machinery, such as corrugated metal hose, square lock and interlock hose/ conduit with more than 25 years of experience. The hoses are widely used in many industries: gas hose, water hose and wire & cable protection circuit, etc..
The sizes are as follows:
Square lock hose and machinery:ID6-ID103
Interlock hose and machinery:ID3-ID350mm on different machine
Annular and corrugated metal hose: ID8 till ID600 on different machine

Our service
 Warranty period of one year
 standard seaworthy package
 Engineers available to service machinery overseas

FAQ for hose making machine

Q: Why choose us for metal hose forming machine?
A: We are most professional manufacturer of hose making machine with more than 25 years of experience
Q: What size can you make?
A: All the sizes from DN8 up to DN400 can be made on different machines
Q: How many different types of machine can you make?
A: Hydraulic metal hose forming machine
  a:DN16-65mm   b:DN25-DN100mm   c:DN32-150mm  d:DN50-300mm  e:DN80-400mm
B: Mechanical hose making machine
  DN8-50mm
C:PU/ Elastomer Metal Hose Making Machine
 a:DN12-100   b: DN50-150   c:DN12-65
Q:Can the hose forming machine be used for bellow making?
Yes, all above hose forming machine can be used for bellow making as well

We need to know following information to quote you correct machineries:
1.Size range you want to make
2.The application of the hose you need, for instance, natural gas hose, water hose, air conditional hose, etc..
3.Wall thickness
