• Model NO.：JL-30KW
• Cooling Water：0.3mpa>=6L,Min
• G.W.：90kg
• Including Parts：Generator, Transformer, Induction Coils, Cable
• Application：Hardening, Welding, Annealing, Quenching
• Working Theory：Electromagnetic Induction Heating
• Warranhty：1 Year
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Transport Package：Plywood Case
• Specification：JL-30KW
• Trademark：Jinlai
• Origin：Guangdong, China(Mainland)
• HS Code：8514400090
• Production Capacity：5000 Sets , Month

ModelJL-30KWInput power desire3 phase 380V±10%  50-60HZ Oscillate power max30KWMax. Input Current38AOscillate frequency30-100KHZCooling Water desire>0.2MPa  2-6L/MinDuty cycle100% 40°CCubageGenerator560x285x580mm
360x265x450mm TransformerNet Weight55kgCable length 2-6(Meters)


List of Accessories In the PackageSingle phase 220V  50/60HZ3 phase 380V 50/60HZOscillate power max5KW15KW25KW30KW40KW50KW60KW80KWMax input current20A37A24A38A48A65A80A105AOscillate frequency100-250KHZ30-100KHZ30-100KHZ30-100KHZ30-100KHZ30-100KHZ30-100KHZ30-80KHZCooling water desire>0.2MPa  2-6L/Min0.3Mpa≥6L/MINDuty cycle80% 40°C80% 40°C100% 40°C100% 40°C100% 40°C100% 40°C100% 40°C100% 40°CNet weight19kg21kg28kg25kg/23kg35kg/30kg45kg/30kg50kg/30kg80kg/85kgCable length2-6(Meters)
