• Model NO.：ALK-TP-12
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Working Pressure：25t
• Process Width：1220 mm
• Process Length：2550mm
• Process Material：Metal Plate
• Transport Package：Steel Tray
• Specification：International Standard
• Trademark：ALUKE
• Origin：China
• HS Code：846210
• Production Capacity：50 Sets,Month

Basic Info.

Model NO. ALK-TP-12 Customized Customized Advantage Use Widely Condition New Working Pressure 25t Process Width 1220 mm Process Length 2550mm Process Material Metal Plate Transport Package Steel Tray Specification International Standard Trademark ALUKE Origin China HS Code 846210 Production Capacity 50 Sets/Month

Product Description

Main functions and characteristics
1. Dealing with multitasks by the system in real time controlling.
2. Easily operate menu and the toolbar with friendship surface.
3. Loading program by graph menu or toolbar for choice.
4. Showing state of operating manner, punch, coordinate of workpiece, rate of punching.
5. Auto-programming by AutoCAD and performing the processing program.
6. Programming with code of ISO NC standard.
7. Editing, rewriting and saving the program.
8. Code of nesting, circulation, and other assistant function.
9. Showing self- diagnosis of the failure.
10. Code explaining, executing, grammar checking and simulation of punching.
11. Following graph and showing the process of punching in time.
12. Super parameter setting.
13. Freely choosing or changing coordinate system of track.
14. Feeding frame the drift by the control of the software.
15. Running by the manner of increment, high and low speed.
16. Counting and the zero clearing a bit.
17. Easily orient the plate material.
18. With the function of returning the start place automatically.
19. With the function of pre-disposal figure.

Technical  specification	unit	ALK-TP 12
Punching  press	T	25
Number  of  stations	_ _	12
Max  part-  dimension	mm	2500× 1250
Max.   plate' s  thickness	mm	6
Hole  dia  and  plate' s  thickness	mm	50.8(δ ≤ 2.9);   31.75(δ ≤ 4.5)
Pace  accuracy	mm	± 0.1
Punch  speed	h/min	140
Max.   one  punching  dia	mm	Φ 50.8
Max.   moving-speed  of  table	m/min	32
Number  of  manipulative  axis	_ _	3
Power	v/w	380/7200
Max.   workpiece  weight	kg	117
Over  all  dimensions (length/width/height)	mm	4900× 3200× 2200
Machine  weight	T	6.5
Main  ordonnance	_ _	AC  servo  motor Industrial  controlling Computer LCD  , Ball  screws liner  guider
Optional	_ _	Punching  tool Assistant  workpiece
