• Model NO.：6060 4 axis
• Condition：New
• Positioning Accuracy (mm)：0.02 mm
• No. of Spindles：Single
• Working Table Size(mm)：600*600
• Spindle Motor Power(Kw)：2.2kw,3.0kw,5.5kw
• Voltage：220V,380V, 50,60Hz
• Dimension(L*W*H)：2170*1460*1870mm
• Weight (Kg)：800
• Control System：Nc Studio, Syntec, Mach3, DSP A18
• Transport Package：Export Standard Wood Package
• Specification：600*600
• Trademark：Remax
• Origin：China
• HS Code：8465990000
• Production Capacity：70 Set,Month

Overview Product ParametersXYZ working area600*600*200mmXYZ accuracy0.02mmXYZ Repositioning Accuracy0.02mmTable SurfaceIron T-slot and moving TableFrameWhole machine lathe Cast by ironXYZ StructureHIWIN square guide rail and Ball screwMax, Power Consumption(without spindle) 3kwMax. Rapid Travel rate15000mm/minMax working speed8000mm/minSpindle power2.2/3.0kw/5.5kw water cooling spindleSpindle speed0-24000rpmDriver and motorsLeadshine Servo Motor and driverWorking voltageAC220V/380V, PH3, 50/60HZCommand languageG codeControl systemDSP / NCstudio /Mach3SoftwareType3 / Artcam /UcancameV9SAMPLE

Certifications

Packaging & Shipping

Company Profile

FAQ

How can I buy this machine from you? ( Very easy and flexible !)
1. Consult us about this product on line or by e-mail.
2. Negotiate and confirm the final price , shipping , payment methods and other terms.
3. Send you the proforma invoice and confirm your order.
4. Make the payment according to the method put on proforma invoice.
5. We prepare for your order in terms of the proforma invoice after confirming your full payment.
And 100% quality check before shipping.
6. Send your order by air or by sea.
