• Model NO.：MS-4B
• Cutting Mode：Plasma Cutting
• Transport Package：Wooden Pack
• Specification：customerized
• Trademark：Meisar
• Origin：China
• Production Capacity：400 Uints,Year

Technical Specification

Product Name

Gantry Flame and Plasma CNC cutting machine

Model

MS-4B

Control System

Fang Ling F2500A

Motor

Panasonic servo motor/ Delta servo motor

Color

Red,Blue,Yellow.

Cutting Mode

Plasma Cutting+ Flame Cutting

Flame Cutting Gas

Oxygen with propane or acetylene

Plasma Torch Gas

Compressed air/N2/O2

Working Area

Cutting thickness

0-150mm

Cutting speed

0-8000mm/min

Operation precision

0.2mm/m

Main Features:

1.CNC gantry flame cutting is mainly suitable for cutting carbon steel within 5-200mm, and steel plates above 200mm require specific air valves; air pipes; and flame cutting torches

2.Flame cutting can realize automatic ignition device; it can greatly reduce the danger caused by industrial ignition and improve work efficiency;

3.Straight single cutting torch can perform high-precision cutting of 6-200mm carbon steel plates;

4.The straight flame cutting lifting device can manually adjust the cutting nozzle and steel plate scheduling manually;

5.Flame cutting gas source uses oxygen + gas (acetylene, industrial propane liquefied gas)

6.(Depending on the thickness of the steel plate; the size of the cutting nozzle used is different, see the flame and plasma reference table below for details)
