Tinned Wire, Enamelled Copper Cable Wire, Bare Copper Wire Twisting Bunching Extrusion Machine

Kunshan Fuchuan Electrical and Mechanical Co., Ltd.
  • Single Wire Diameter：0.05-0.28mm
  • Fit for Bobbin：Diameter 300,250
  • Main Motor Power：3.7kw
  • Magnetic Powder Clutch：0.6kgf
  • Max Rotating Speed：3500rpm
  • Operation Mode：Touchscreen Operation

Base Info

  • Model NO.：FC-300B-1
  • Pitch Area：1.6-21.6
  • Direction of Lay：Optional for Right or Left
  • Stranding Section Area：0.0137-0.45square mm
  • Transport Package：Standard Packing
  • Specification：ISO9001
  • Trademark：Fuchuan
  • Origin：Jiangsu Kunshan
  • HS Code：8479111000
  • Production Capacity：50sets,Month

Description

Equipment modelsFC-300BTwisting usageIt is applied to the twisting of aerospace, medical equipment, cellphone and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires.Single wire dia(mm)φ0.05-φ0.28Stranding section area (mm²)0.0137-0.45Pitch(mm)1.6-21.6(24zones)Direction of layOptional for right or leftOuter dia*bore*outer widthφ300*φ30*185
φ250*φ30*185Max rotating speed3500(7000twist)Main motor power3.7KWInverter power3.7KWTension control methodTouch screen+PLC+magnetic powder clutch,it may ensure the constant tension from empty bobbin to full bobbinMagnetic powder clutch0.6kgfProtectionMachine will automatically brake when wire inside and outside is broken,the machine will automatically stop when the preset length is arrived.Brake modeElectromagnetic brakeTraversing methodRolling ring drive units,winding pitch and breadth are adjustableOperation modeTouch screen operationDimension(mm)2300L*1100w*1330HTinned Wire, Enamelled Copper Cable Wire, Bare Copper Wire Twisting Bunching Extrusion Machine
