Gw Carbide - Grinding Wheels Use on Vollmer CNC Machine Excellent Finishing
Zhuzhou Grewin Tungsten Carbide Tools Co., Ltd.- Certification：ISO9001
- Customized：Customized
- Application：Metal Cutting Machine, Metal Processing Machinery Parts
- Material：Diamond
- Abrasive：Superabrasive
- Types：Surface Grinding Wheel
Base Info
- Model NO.：1A1, 1V1, 1A1r, 4A2, 6A2, 9A3, 11V9, 12V9, 14A1
- Grain Size：70#
- Cylindricity：<0.5
- Circular Degree：<0.05
- Technics：Electroplating
- Working Style：Surface Grinding
- Shapes：Circular
- Delivery Time：7-10 Days
- Type：1A1, 1V1, 1A1r, 4A2, 6A2, 9A3, 11V9, 12V9, 14A1
- Semi Finish Grinding：Grit 140,170---230,270
- Fine Grinding：Grit 270,325---325,400
- Polishing：Grit W40 to Fine Powder
- General Coarse Grinding：Grit 80,100---120,140
- Bond：Resin, Vitrified, Metal, Electroformed Bond
- The Ranges：Diamond & CBN Wheels, Diamond & CBN Cutting Blades
- Working Fields：Tools, Molds, Bearing, Compressor, Ceramics
- Transport Package：Plastic Box, Standard Export Carton
- Specification：100% raw material
- Trademark：GW or OEM
- Origin：Zhuzhou
- HS Code：6804210000
- Production Capacity：50000 Pieces Per Month
Description
Range of roughness (Ra) Unit:μmGrain size Resin bond (B) Metal bond (M) 80/100 ~100/120 --- 3.2---1.6 100/120~170/200 0.8---0.4 1.6---0.8 170/200~230/270 0.4---0.2 0.8---0.4 325/400~M12/22 0.2---0.1 M10/20~M3/6 0.1---0.05 M3/6~M0/1 0.05---0.025
3- Conventional Grinding Wheel Variety
* Shape code: 1A1
* Shape code: 2A2
* Shape code: 12C2
* Shape code: 4B1, 1V1
* Shape code: 1F1, 1FF6
* Shape code: 11V9
* Shape code: 12A2, 12V9, 12V2
From material to your hand
3- Conventional Grinding Wheel Variety
* Shape code: 1A1
- Parallel grinding wheel: suitable for all types of cylinder grinding, surface and end face grinding.
- Centerless grinding wheel: suitable for processing the outer circle of bar and thread. Divided into rough grinding, precision grinding and polishing.
* Shape code: 2A2
- Cup & ring type grinding wheel: applicable to the processing of various materials of the end surface grinding, can be processed two end face at the same time.
* Shape code: 12C2
- Abrasive disc: It is suitable for various materials' grinding and chamfer.
- Cup-shaped grinding wheel: Suitable for all types of surface and end grinding.
* Shape code: 4B1, 1V1
- Single bevel wheel: suitable for precision grinding and notching.
* Shape code: 1F1, 1FF6
- Arc grinding wheel: suitable for various types of molding grinding.
* Shape code: 11V9
- Bowl-shaped grinding wheel: Suitable for end, flat and edge grinding of cutter.
* Shape code: 12A2, 12V9, 12V2
- Dish-shaped grinding wheel: Suitable for the cutting tool's end face, surface and the cutter edge grinding.
