180ton Cold Chamber Die Casting Machine for Aluminium
Ningbo Yinzhou Hybers Imp.& Exp. Co., Ltd.- Control Type：PLC
- Customized：Non-Customized
- Condition：New
- Automatic Grade：Automatic
- Certification：CE
- Type：Special Casting
Base Info
- Model NO.：J1118K
- Die Locking Force：180tons
- Suitable for：Aluminum Alloy, Brass Alloy
- After-Sales Service Provided：Engineers Available to Service Machinery Overseas
- Warranty：12 Months
- PLC：Mitsubishi
- Motor Voltage：380V, 220V, 415V etc.
- Production Experience：Since1987
- Transport Package：Full Container Load
- Specification：SGS
- Origin：Ningbo, China
- HS Code：8454301000
- Production Capacity：300sets,Year
Description
Basic Info.
Model NO. J1118K Die Locking Force 180tons Suitable for Aluminum Alloy, Brass Alloy After-Sales Service Provided Engineers Available to Service Machinery Overseas Warranty 12 Months PLC Mitsubishi Motor Voltage 380V, 220V, 415V etc. Production Experience Since1987 Transport Package Full Container Load Specification SGS Origin Ningbo, China HS Code 8454301000 Production Capacity 300sets/YearProduct Description
First J1118K: made in 1981.Suitable for Al, zinc alloy die casting in the auto parts, handles etc. fields.Best price.Direct customs service.
| Project | unit | J1118K |
| Die locking force | KN | 1800 |
| Size of moving platen (H×V) | mm | 720×719 |
| Inner space between the bars (H×V) | mm | 480×480 |
| Thickness of die block (Min.-Max) | mm | 200-580 |
| Stroke of moving platen | mm | 385 |
| Ejection stroke | mm | 85 |
| Ejection force | KN | 109 |
| Injection force | KN | 230 |
| Injection stroke | mm | 350 |
| Injection position | mm | 0,-70,-140 |
| Diameter of shot sleeve | mm | 50,60 |
| Dosage of fluid metal per shot (AL) | kg | 1.3,1.9 |
| Injection Pressure (Min-Max) | MPa | 117,81.3 |
| Max Projecting area of casting | cm 2 | 221 |
| Dry cycle | S | 7 |
| Pipe line pressure | Mpa | 13 |
| Motor power | kw | 15 |
| Machine weight | kg | 7000 |
| Overall dimensions (L×W×H) | mm | 5600×1280×2560 |
