4 Spindle Flange and Hex Nut Tapping Machine
HARBIN RAINBOW TECHNOLOGY CO., LTD.- After-sales Service：at Site Service, Online Video
- Warranty：12 Months
- Spindle Number：4 Spindle
- Color：Green
- Model：Ldh Model
- Size：M3-M30
Base Info
- Model NO.：LDH model
- Transport Package：Into Container
- Specification：M3-M30
- Trademark：Rainbow
- Origin：China
- HS Code：8459700000
- Production Capacity：1000 Sets Per Year
Description
ModelSize No. of
Spindle Productivity (pcs/min.) Main Motor (kw) Motor of Material Mixing (kw) Oil Pump (kw) Air Pressure (kg/cm) Dimension(L x W x H/mm) Weight (kg) Flange Hex LDH-M8-4 M5 4 140 200 0.75-4 0.55 0.25 2-3 1450×1600×1800 1110 M6 4 130 180 M8 4 120 160 LDH-M12-4 M10 4 100 140 1.5-4 0.55 0.25 3-4 1500×1900×1750 1160 M12 4 90 120 M14 4 80 100 LDH-M18-4 M16 4 60 80 2.2-6 0.75 0.25 4-5 1700×2000×1800 1280 M18 4 50 70 LDH-M24-4 M20 4 40 60 2.2-8 1.1 0.25 4-6 1750×2100×1850 1400 M22 4 30 50 M24 4 25 40 LDH-M30-4 M27 4 20 32 3-8 1.1 0.25 4-7 1750×2100×1850 1400 M30 4 16 28
Exhibitions
Package
We can supply standard four spindle nut tapping machine also non-standard one spindle machine for tapping specialized nuts or anchors. If you have any question, pls feel free to contact me.
Spindle
Exhibitions
Package
We can supply standard four spindle nut tapping machine also non-standard one spindle machine for tapping specialized nuts or anchors. If you have any question, pls feel free to contact me.
