• Model NO.：Lt series
• Max. Number of Block：9
• Certification：CE
• Condition：New
• Power Supply：380,415,440,220V
• Power：15-18.5kw
• Max Speed of Drawing：7m,S
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Diameter of Block：350-600mm
• Suitable Material：Low Carbon Steel,Medium Carbon,High Carbon Steel
• Transport Package：in Nude or Wooden Case
• Specification：2400*1100*1100mm
• Trademark：CANDID
• Origin：China
• HS Code：84633000

Type

LT1-12/350 Water-tank

Dia. Of Coiling Block

φ350mm

Wire Drawing Mould

12pcs

Dia. Of Inlet Wire

φ2.2mm

Min. Dia. Of Outlet Wire

φ0.7mm

Total Condensation

86%

Average Condensation

16%

Speed Of Drawing

250-400m/min

Power Of Motor

15-18.5kw

Dimension

2400×1100×1100mm

Weight

1800kg

Type

LT1-19/200 Water-tank

Dia. Of Coiling Block

φ200mm

Wire Drawing Mould

19pcs

Max. Dia. Of Inlet Wire

φ1.6mm

Min. Dia. Of Outlet Wire

φ0.3mm

Total Condensation

~96%

Average Condensation

~15.5%

Speed Of Coiling Block

400~700m/min

Power Of Motor

YCT250-4/22kw

Dimension

2310×1440×1160mm

Weight

~4000kg

Type

LT1-20/280 Water-tank

Max. Dia. Of Inlet Wire

3.0mm

Min. Dia Of Outlet Wire

0.35mm

Speed Of Drawing

900m/min

Wire Drawing Mould

19pcs

Cone Pulley

4pcs

Dia. Of Capstan

16%

Max. Size Of Spool

250-400m/min

Power Of Drawing Wire

30-37.5kw

Power Of Spooling Motor

YLJI32-25N.m/4 n=1250rpm

Dimension

6500×1800×1600mm

Weight

5000kg

Guarantee and after-service:
1. Guarantee time:one year since machine was at buyer' factory within 12 months against B/L date
2. Within guarantee time, if any components are broken under normal condition, we can change for free.
3. We can send our best technician to buyer's factory for installation, debugging and training.
4. Complete installation instructions, circuit diagram, manual operations and machine layout.
5. Technical support by e-mail.
