• Model NO.：1450 4Hi
• Trademark：moran
• Origin：China
• Production Capacity：1

Basic Info.

Model NO. 1450 4Hi Trademark moran Origin China Production Capacity 1

Product Description

Hebei Moran Environmental Protection Technology.,Ltd is one of main metallurgical equipment factory in China. our products include new and used steel and aluminum rolling mill,2hi 4hi 6hi 8hi to 20 hi rolling mill machine, skin pass mil, tension leverler, tension leverler and skin pass mix mill, caster, steel coating line, pickling line ,annealing furnance,grinder, and other related equipment and its parts.our machine has been exported to many country and enjoy a very good reputation among our users.

for more detail pls contact us





1. Unit Type:Four rollers are adopted (advantages: strong adaptability, good shape, high precision and strong stability);
2. Unit specification:0.15~6.0mm X 700~1300mm;
3.  Unit speed: 10M/S(Max)
4. Left and right coiling tension: 30T (Max), uncoiling tension: 10T (5m/s).
5. Inner diameter of incoming coil: 508-610mm, inner diameter of finished coil: 610mm
6. Outer diameter of coil: 2200mm
7. Max coil weight: 25 tons
8. Lubricant: Emulsion
9. Annual capacity: 120,000 tons/year (skin pass 0.3x1250mm)
10. Maximum rolling force: 1800T
11. Motor power: main motor: 1500kw-2 sets

Coiling motor: 1700kw-4 sets
Unwinding motor: 540 KW-1
Tension motor: 355x2 = 710kw, 280x2 = 560kw

1. Total installed capacity: DC 11610KW

The specification of the mill:  F450/F1050´1450mm
* : 6.00mm
The maximum thickness of finished steel coil:6.00mm
* : 0.3mm(),:0.15mm;
The minimum thickness of finished steel coil:0.3mm( rolling); 0.15mm( when leveling)
* : 1300mm
The max width of steel strip:1300mm
* :     700mm
The Min width of steel strip:700mm
* :     2200mm
the Max outer diameter: 2200mm
* :Φ508-610mm,:Φ610mm
the inner diameter of incoming steel coil:Φ508-610mm
the inner diameter of finished steel coil:Φ610mm
* :           25T
The max steel coil: 25T
* : 18000KN
the max rolling force:18000KN

* : 121.5KN&m
the Max Rolling torque:121.5KN&m
* : 600m/min
Max rolling speed: 600m/min
* :   E450mm
                 E410mm
the diameter of working roll: F450mm new roll
                                 F410mm used roll

The diameter of Support roll:F1050mm new roll
                                 F980mm used roll

*
Diameter of tension roll: F610mm

Anti-wrinkle roll diameter: F255mm
