• Model NO.：ND-650-SA
• Specification：standard container
• Trademark：Nianda
• Origin：China
• Production Capacity：5

Basic Info.

Model NO. ND-650-SA Specification standard container Trademark Nianda Origin China Production Capacity 5

Product Description

1. Equipment Description
   1. It is supplied for solution and aging treatment for aluminum castings.

.

1. Service life / Diversity / Changes over time //

Several kinds and heterogeneous parts shall be treated on this unit. The unit is designed for a capacity of 6 ton/hour and unit part weights between 1 to 2.5 tons (total weight part and rack)

: 6/h
+: 1-2.5.

1. Energy sources specification of customer workshop:
   1. Power source:3x480V±10% , 60Hz

:3x480V±10% , 60Hz
The installed capacity:500KVA
:500KVA

1. Compressed air: dry and oil-free

:,
Operating pressure: 6 bars ± 0.5 minimum
:6±0.5
The compressed air pipeline interface:1"
:1
Compressed air Consumption:1m³/h
:1m³/h

1. Water pressure :3 bars ± 0.5 minimum

:3 bars ± 0.5
Pipe interface:4"
:4
Water Temperature:28ºC
:28ºC
water supply volume:100m³/h
:100m³/h

1. Natural gas pressure outlet from General Distribution System  : 1Bar².

:1Bar
Gas calorific value:8400~8900Kcal/Nm³
:8400~8900Kcal/Nm³
Gas pipeline interface:3"
:3"
Maximum Gas Consumption:315Nm³/h
:315Nm³/h
Average Gas Consumption:215Nm³/h
:215Nm³/h
