• Model NO.：Coating Production Line
• Support：Field Application Support
• Service：After Sale Service Is Available
• Transport Package：Seaworth Packing
• Specification：Container
• Trademark：SUNNY
• Origin：Hubei, China
• HS Code：8479819000
• Production Capacity：30 Set,Sets Per Year

Basic Info.

Model NO. Coating Production Line Support Field Application Support Service After Sale Service Is Available Transport Package Seaworth Packing Specification Container Trademark SUNNY Origin Hubei, China HS Code 8479819000 Production Capacity 30 Set/Sets Per Year

Product Description

Line Main Properties :

1. Line Type : horizontal, vertical, combination of vertical and horizontal

2. Specification / Thickness : cold rolled strip / min. 0.12mm, max. 2.5mm
                                           hot rolled strip / min. 1.5mm, max. 5mm

   Width : min. 550mm, max. 1500mm

3. Speed in Process Section: max. 200m/min (240m/min for GL)

4. Continuous Annealing Furnace:

Furnace Type: horizontal, vertical, combination of vertical and horizontal (L type)

Heating Method: Gas non-oxidation heating (NOF), Gas radiant tube heating (RTF), Electric radiant tube and electric resistance tape heating

Cooling Method: Shielding gas regular air jet cooling, rich hydrogen high speed air jet cooling

5. Zinc pot: jet flow ceramic induction zinc pot (GL line with pre-melting pot)

6. Air knife: single injection advanced air knife, multi-cavity air knife

7. Skin Pass Mill: 300T-800T, 4-roll wet skin pass

8. Energy saving method: high efficiency radiant tube combustion air heat exchanger, fume duct combustion    air heat exchanger, fume duct hot air and hot water heat exchanger, hot shielding gas recycle injection pre-      heating strip, fume heat radiant before non-oxidation heating pre-heating strip, light fiber furnace lining


Packing & Shipping

1. Export standard wooden cases packed in suitable container.

2. Cooperate with reliable shipping company to ensure the delivery time.

3. Customized Packing is allowed.

Certificate and Award

SUNNY has been awarded as "National Hi-tech Enterprise" by the Government and has undertook "China

Torch Plan" (CTP, by China government) of "Wide strip continuous galvanizing process equipment

completed". At the same time, SUNNY has become a famous trademark of China by China Trademark

Bureau.

GB/T 19001-2016/ISO 9001:2015



Aftersale Service:

We can provide site technical support as well as remote technical support;

Worldwide Business:



Our Vision

To be worldwide known equipment supplier by our advanced strip processing technology and superior services.

Our Mission
Based on the strip processing technology, provide the advanced strip solution for customers at home and aboard.

Our Core Value
Integrity, Respect, Fairness, Diversity

Our Spirit
Innovation, Solidarity, High Efficiency

Exhibition:
ITIF ASIA & PAKISTAN IMPORT & EXPORT FAIR




Vietnam ISME Exhibition












Iran International Industry Exhibition
