Beta 300 PRO Automatic/Manual Metallographic Cutting Machine
Trojan (Suzhou) Material Technology Co., Ltd.- Customized：Non-Customized
- Layout：Vertical
- Cutting Material：Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel
- Automatic Grade：Automatic, Manual
- Power Source：Electric
- Cutting Mode：Saw Cutting
Base Info
- Model NO.：Beta 300
- Warranty：12 Months
- Transport Package：Standard Export Package, Wooden Case
- Trademark：trojan
- Origin：Suzhou China
- Production Capacity：5000 Pieces,Year
Description
Items
Beta-300 Pro
Beta-300 MY
Beta-300 M
Safety
Emergency-Stop
Brake on cut-off wheel and table-feed
Brake on cut-off wheel
Door-open
Current overload
Automatic adjustment
Trip protection
Joystick misoperation
Two hand control
--
--
Max. Wheel Diameter
Φ300mm
Φ300mm
Φ300mm
Min. Wheel Diameter
Φ200mm
Φ200mm
Φ200mm
Max. Cutting capacity.
Φ110mm
Φ110mm
Φ110mm
Max. Cutting Capacity. HxD
80x200mm
80x200
80x200
Z-Axis Travel, mm
150
150
150
Y-Axis Travel, mm
220
220
220
X-Axis Travel, mm
100
-
-
T-table Dimensions,mm
280x536(636)
280x636
280x636
T-Slot Dimension, mm
12
12
12
Cutting motor power, Kw
4
4
4
Power Input
AC 220V/380V, 50/60Hz,5.5Kw
Wheel Speed, RPM
1000-3500
2800
2800
Control Panel
7 inch Touch Screen
7 inch Touch Screen
Buttons
Cutting
Method
Smart Cutting
Auto
Auto
Manual
Chop Cutting,Z-Axis
Auto
Manual
Manual
Table Feed Cutting,Y-Axis
Auto
Auto
Manual
Pulse Cutting
Y-Axis
Z-Axis
Y-Axis
-
Step Cutting
Yes
-
-
Cutting Feed rate,mm/s
0.02-3
0.02-3
-
Laser Alignment
Yes
Option
Option
Weight,Kg
250
250
250
Size WxDxH(OPEN), CM
92x100x70(117)
92x100x70(117)
92x100x70(117)
Recirculation coolant, L
80
80
80
Specifications
1.Beta 300Pro vertical metallographic cutting machine has a novel and creative design, its performance can compare with the international similar product(Like Buehler)2.All use Schneider system, low pressure control, safe and reliable.
3.Electronic brake technology, motor can be stopped immediately, safe enough.
4.Large enclosed cutting room.
5.T - type worktable, double quick clamping fixture, which is beneficial to clamping all kinds of specimen.
6.Oversized closed cutting operation room.
7.Three different cutting modes: cut cutting, reciprocating cutting, cutting (for different materials, diameters, hardness)
