Electric Equipment Wire Making Machinery with Energy Saving Spare Parts for Steel Carbon Steel Wire/Welding Wire/Spring Wire
Jiangsu Zhixuan International Trading Co., Ltd.- After-sales Service：Free Maintenance Service Within Warranty Period
- Warranty：12months
- Type：LZ Straight-Line Metal Drawing Machine
- Usage：Wire, Rope Wire, Prestressed Steel Wire, Standard Parts
- Metal Material：Steel
- Outlet Diameter：0.5-7.0mm
Base Info
- Model NO.：LZ Straight-Line Metal Drawing Machine
- Max.Inlet Wire Dia.：6.5mm
- Block Dia.：560mm
- Max. Number of Block：14
- Certification：REACH, RoHS, ISO
- Condition：New
- Block Diameter：560mm
- Maximum Number of Block：14
- Maximum Tensile Strength of Inlet Wire：1200MPa
- Maximum Diameter of Inlet Wire：6.5mm
- Minimum Diameter of Outlet Wire：1.4mm
- Maximum Drawing Design Speed：20m,S
- Actual Drawing Speed：10m,S
- Motor Power：22-45kw
- Transport Package：Container Shipment
- Specification：50X3X1.5m
- Trademark：Zhixuan
- Origin：Jiangsu China
- HS Code：846310
- Production Capacity：30000t,Year
Description
4.4 Sand belt unit
- Automatic adjust position of belt
- Running will be synchronized with drawing machine
- Horizontal spooler for max 800mm reel
- Traverser unit is driven by independent motor, adopt gear tooth belt to do transmission, traverse return position can be adjusted, the reel is fixed by pneumatic cylinder
4.6 Internet of Things
4.7 Water and electrical configuration requirements
| Power supply | 380±10%,50HZ, three-phase five-wire (ground reliable grounding), power configuration and cable specifications as shown in the basic diagram 380±10%,50HZ. |
| Air supply | Pressure ≥ 0.6 MPa |
| Cooling water | Pressure ≥ 0.1mpa, water temperature ≤30ºC |
