Base Info
- Model NO.：HY3040 5axis
- Carving Material：Aluminum
- Controlling Mode：CNC
- Main Axle Rotational Speed：≤24000rpm
- Milling Cutter Diameter：10mm
- Feeding Height：150mm
- Certification：CE
- Warranty：12 Months
- Customized：Non-Customized
- Condition：New
- Effective Working Travel：300(X)mm*400(Y)mm*150(Z)mm
- Shape Dimension：655(L)mm*604(W)mm*550(H)mm
- Frame Materials：Aluminum Alloy 6063 and 6061 The Unique and Dedica
- X,Y,Z Axis Stepping Motor Type：57 Two-Phase 3A 180n.Cm 76mm Length
- a,B Axis Stepping Motor Type：57 Two-Phase 4A 180n.Cm 112mm Length
- Support 4th Axis(Rotary) Maximum Clampin：Center Height 65mm, 3 Jaw 80mm Chuck, Maximum Clam
- 5th Axis Working Travel：120(X)mm*120(Y)mm*80(Z) 360 Degree 30-90 Degree
- Principal Axis Collet：Er11 1-7mm; Er-20 1-13mm
- Repeat Accuracy：0.05mm
- Spindle Precision：Radial Beat Accuracy 0.03 mm
- Operating System：Win10 and Below
- Maximum Speed：0-4000mm,Min
- Trademark：chinacnczone
- Transport Package：95kg, 80*74*90cm
- Origin：Shenzhen, Guangdong
